PRO SYSTEM SPECIFICATION

DPSS 1 - 1.5 watt White RGB Laser.
Dimensions: L= 470mm x H=215mm x D=215mm
Built in functions I Individual laser color power adjustment, and full scanner control. Mirror, X/Y swap,
Adjustable Image size X and Y. Low noise Fan RPM control.
Protection features
Full temperature control with over temperature switch..

ilp LASER SOFTWARE

Pangolin Laser Software Options:
See Pricelist for Further Details
ILP Lasermedia Latest Edition

Multimedia PC or Laptop Pangolin Operating System

Precision " Micro " Projector enclosure
High Speed CTI / ScannerMax Galvos
Electronics and Cabling

Available in CLUB and ADVERTISING Configurations
Inclusive of 12 month Warranty Parts & Labor

MULTI-COLOR LASER DISPLAY APPLICATIONS


ADVERTISING / LEISURE VENUES / CLUBS / BARS
The MICRO-COLOR white light laser projection system addresses the need for an extremely small, portable, higher powered, white light laser source for entertainment and advertising applications
MICRO-COLOR the most versatile white light laser system available.

SOFTWARE

Pangolin Laser Software Options
See Pricelist for Further Details

INSTALLATION

See Pricelist for Further Details

LASER SPECIFICATIONS 1w

RGB 1.0 Watt
Laser output mw RED GREEN BLUE 300 500 300
Wavelength nm 640 532 473
Beam Diameter mm 2.5mm
Divergence mrad 0.8<
Ext Modulation ( Analog) Hz 15000
Operating temp 10-40
Warm up time sec< 120 20 120
Operating Lifetime hrs 10000
